The arched roof structure consist of standard 290*290mm mast truss sections on special small bases. Integrated jacks and a few special corners assures the fit for the triangular 290*290mm arches. Between the arches standard hook on bars are required for extra stability and to support the canopy.
AVAILABLE IN DIFFERENT SIZES
The Arc Roof comes in various dimensions 10x8m, 8x6m, 8x4m and 6x4m and all roofs are available Version. The top canopy is tightened with tubes and ratchet straps and the wall canopies can be either in full PVC or the wind through mash.
The Arc Roof is on many occasions the perfect solution by its low self weight, minimum of volume, easy and fast manual set up by 2 persons and a nice appearance.
Size: 10x8x6m
wing wide: 2m
wing load: 1500kg
Tower truss size: 290*290mm
Maint ube: 50x3mm
Roof Structure: 290*290mm
PA Wing possible: Yes
Max. Load PA Wing:1500 Kg.
Width: 10m.
Depth: 8m
Height: 6m
